   Mini Computers -> 4Gen CPU HTPC
Eglobal New M3 series mini pc computer intel core i5 4200U ultra mini desktop pc
Eglobal New M3 series mini pc computer intel core i5 4200U ultra mini desktop pc
Item No.:M3-4200U
Catalogue:EGLOBAL
Units:unit
Simply description:Eglobal New M3 series mini pc computer intel core i5 4200U ultra mini desktop pc
CPU:Onboard Intel Core i5-4200U
Memory:2* SO-DIMM DDR3L Slot
Storage:SSD: 8G/16G/32G/64G/128G/256G/512G/1TB
Support OS:Windows 7/Windows 8/Windows 10/Linux
WiFi:optional
Case Material:aluminum alloy
Product Dimensions:174*127*37MM
Color:black/silver/blue
OEM:accept
Quantity: unit
eglobaltech Favorites
  Detail description

Eglobal New M3 series mini pc computer intel core i5 4200U ultra mini desktop pc

You can buy sample unit to test directly if PayPal is available for you.
The link is for the following Specification: Barebone System

- No RAM
- No Storage
- 300M WIFI with Dual Antennas
-Windows 10/Linux
- Including DHL/FedEx/UPS/EMS/Postage shipping

The Package includes:
1 * Mini PC Device
1 * EU/AM/BR/AU standard Power Adapter
1 * Set of SATA power and data cables(for 2.5" hard drive installation)
1 * Plastic Stand Holder
2 * WiFi Antennas
1 * HDMI Cable
1 * VESA mount(optional)

Features:

Full aluminium silver color shell, Exquisite production craft on ouside design

Fanless system without cooling fan and slim design 174*127*37MM

Low consumption TDP only 15W

Can stand up or can be mounted back of monitor or wall

Package include the mini pc device, power adapter, a VESA mount, dual WiFi antennas(optional), a HDMI cable( as a gift), a Screw Bag, Warranty Card

Specifications

CPU

Onboard Intel Core i5-4200U 1.7GHz Dual Core Four Thread processor

Core (FSB)

100MHz

CPU Technique

22nm

L3 Cache

3MB SmartCache, CPU Integrated

BOIS

AMI BIOS, ACPI supported

Support calls on function automatically

Support Wake-On-LAN

Chipset

Intel Haswell

Memory

2* SO-DIMM DDR3L Slot

Support 4GB/8GB/16GB

Dual Channel, DDR4-2133, LPDDR3-1866, DDR3L-1600

Storage

SSD: 8G/16G/32G/64G/128G/256G/512G/1TB

HDD: 160G/320G/500G/1TB

Operating System

Windows 7/Windows 8/Windows 10/Linux

Audio

ALC897 chip, 7.1 channel sound

Intel Lynx Point-LP HDA

Network

Onboard Realtek RTL8168E PCI-E Gigabit Ethernet NIC

Onboard RTL8111DL10/100Mbps/1000Mbps BaseT LAN

Video

Intel HD Graphics 4400

I/O port

front panel ports

2*USB2.0, 4*USB3.0, 1* Power indicator and switch

Backside ports

1*HDMI, 1*VGA, 1*LAN, 1*MIC, 1*SPK, 2*WiFi antennas

Internal ports

1*M-SATA3.0 port, support 6Gb/s

1*SATA3.0 port, support 6Gb/s

1*mini-PCIE port(WIFI&Bluetooth)

Power and Working Environment

Input

DC100-240V AC/50-60Hz

Output

DC 12V~19V/5A

Operating Temperature

0/70 Centigrade(32F~140F)

Storage Temperature

-20/+85 Centigrade

Relative Humidity

0%~90% (non-condensing)

Energy-saving

Support Energy-saving technology, Speedstep

64 bit computing

Support 64 bit computing

Virtualization

Intel VT-x

Hyper-threading

Support Hyper-Threading

Product Dimension & Details

Size

174*127*37MM

Weight

1.5KG

Consumption

15W

Shell

Silver color aluminum alloy

Package Content

Mini PC device, power adapter, a VESA mount, dual WiFi antennas(optional), a HDMI cable( as a gift), a Screw Bag, Warranty Card
